Mini Fiber Photo-detector

High Responsivity Mini Fiber Photo-detector

Mini Fiber Photo-detector

关键性能

●  High responsibility
●  Small size device



The Mini Fiber Photo-detector is a highly responsive and compact optical sensing component, designed to efficiently detect optical signals across a broad wavelength spectrum. Its miniaturized form factor makes it ideal for integration into space-constrained fiber optic systems, delivering reliable performance and precision.

Parameter

Unit

Value

Operating Wavelength

nm

1250~1650

Responsivity (Dual fiber)

mA/mW

≥0.9

Dark Current

nA

≤1.0 (@25°C, 5V)

Forward Current

mA

≤10

Reverse Voltage

V

≤5

Capacitance

pF

≤6 (Vr=5V, f=1MHz)

Return Loss

dB

≥45

Polarization Dependent Loss

dB

≤0.15

Polarization Mode Dispersion

ps

≤0.1

Temperature Dependent Rate

%

±5 (@Responsivity)

Fiber Type

/

G657A1/A2/B3

Operating Temperature

-25~+70

Storage temperature

-40~+85



  • Optical network signal monitoring

  • Fiber optic communication systems

  • Optical sensing applications

  • Data center fiber optic integration
